Overview

The CP PLUS CP-UNC-DA81L3C-LQ is a high-performance 8MP Dual Light Dome Camera designed for round-the-clock security in residential, commercial, and industrial setups. With 4K ultra HD resolution (3840 × 2160) and dual light technology, this camera ensures exceptional video clarity even in total darkness up to 30 meters.

Advanced Imaging Technology

Featuring a 1/2.7″ 8MP PS CMOS Image Sensor, the camera provides vibrant, sharp images with low noise. Its DWDR, 3D NR, BLC, HLC, ROI, and digital watermarking enhance image quality under challenging lighting conditions, ensuring that every detail is visible.

Dual Light Night Vision

Equipped with IR and warm light up to 30 meters, the camera delivers reliable night vision for both dark and dimly lit environments. The built-in microphone captures audio along with video, providing comprehensive surveillance coverage.

Flexible Lens and Viewing Angles

• Lens Options: 3.6mm fixed (optional 2.8mm)

• Angle of View: Wide coverage, with detection range up to 98.7 m (DORI)

• Pan/Tilt/Rotation: Pan 0°–360°, Tilt 0°–78°, Rotation 0°–360°

Smart Video Features

The camera supports triple stream video, H.265/H.264/MJPEG compression, and integrates with smart NVR systems for intelligent search and event extraction. Frame rates are adjustable, supporting smooth real-time monitoring and efficient storage.

Robust Network & Protocols

With PoE (802.3af) and Ethernet support, installation is simplified. The camera supports multiple protocols including ONVIF, IPv6, HTTP/HTTPS, SSL, SNMP v3, ensuring secure and seamless connectivity.

Durability & Reliability

• Weatherproof: IP66-rated, metal + plastic casing

• Operating Conditions: –40°C to 55°C, humidity ≤95% RH

• Power Consumption: Max 5.8 W (PoE)

Specifications at a Glance

• Resolution: 8MP (3840 × 2160) @1–20 fps

• Lens: 3.6mm fixed (optional 2.8mm)

• IR & Warm Light Range: 30 meters

• Smart Features: DWDR, 3D NR, ROI, Digital watermarking

• Audio: Built-in mic, Audio Compression G.711a/G.711Mu/PCM/G.726

This STQC-approved 8MP Dual Light Dome Camera offers superior video clarity, smart monitoring, and durability, making it a premium choice for security-conscious users.
