Prama PT‑HTD70F0E‑PF is a 2MP plastic dome camera with built‑in white light. It supports HD‑TVI, AHD, CVI, and CVBS video signals. The camera uses a 2MP CMOS sensor and comes with a 2.8 mm or 3.6 mm fixed lens. So, you can choose wider views for corridors or tighter coverage for specific indoor areas.

Therefore, it is ideal for homes, shops, offices, and indoor spaces that need clear 24/7 monitoring with color‑night light.

White light performance

The camera has a bright white light up to 20 m. As a result, it can switch to white light for color images in low‑light or security‑trigger situations.

The minimum illumination is 0.01 Lux at F1.6, or 0 Lux with white light. Smart light helps avoid overexposure and keeps images clear. DNR (digital noise reduction) improves image quality in dim scenes.

Design and suitability

The camera uses a compact plastic dome housing suitable for indoor environments. It runs on standard 12 VDC power and uses a simple coaxial connection. For example, you can mount it on walls or ceilings with common dome brackets.

So, it fits discreetly in offices, lobbies, shops, and other indoor areas.

Video output and OSD menu

This model supports HD‑TVI, AHD, CVI, and CVBS video output. So, it works with many modern DVRs and can also connect to older analog systems.

You can adjust settings such as resolution, light mode, and signal type using the on‑screen OSD menu. As a result, setup and tuning become easy at the DVR or monitor.

Key specifications

• Sensor: 2MP CMOS.

• Resolution: 1080P Lite (2MP).

• Lens: 2.8 mm or 3.6 mm fixed.

• Illumination: white light up to 20 m.

• Min. illumination: 0.01 Lux @ F1.6, 0 Lux with white light.

• Power: 12 VDC.

• Noise reduction: DNR.

• Video output: HD‑TVI, AHD, CVI, CVBS.

• For more details, visit Prama official website
